Description
- Flux EMH-3s Brushless ESC (Part # 112851)
- Designed to be used with the Flux MMH 4000kV Brushless Motor (Part # 106768) Sold Separately
- Waterproof, Dustproof
- Three Running Modes:
- Racing (Forward and Brake)
- Bashing (Forward, Brake and Reverse)
- Rock Crawler (Instant Switch from Forward to Reverse)
- Eight Step Drag Brake Adjustment from 0-100%
- Six Auto LiPo Cut Off Settings, None or 2.5-3.4V per Cell
- Nine Punch Start Mode Settings from Soft to Aggressive
- Four Steps of Maximum Brake Adjustment from 25-100%
- Four Steps of Maximum Reverse Force Adjustment from 25-100%
- Three Steps of Initial Brake Force Adjustment from 0-40% plus Option to make IBF Equal Drag Brake Setting
- Three Steps of Neutral Range Adjustment from 6-12%
- Eight Steps of Motor Timing Adjustment from 0-26.25 Degrees
- Overheat Protection
- Multiple Protection, Auto LiPo Protection, Low Voltage Cutoff, Throttle Signal Loss
- 13AWG Battery Leads
- Deans Ultra Male Connector
- Universal Receiver Connector
- 4mm Female Motor Connectors
- On/Off Switch
- Specifications:
- Constant Current: 80A
- Burst Current: 540A
- Resistance: 0.0004 Ohm
- Maximum Battery Input 3s, 11.1v
- Motor Limit:
- 2S LiPo: Off Road, 60900kV
- 3S LiPo: Off Road 4000kV
- BEC: 6V/2A
- Dimensions: 2.0×2.2×1.4″ (50.5×56.2×35.4mm)
No term warranty provided by Dollar Hobbyz. No liability shall be assumed nor accepted for any damages, losses or costs resulting from the use of this ESC.
